Product Description
Product Parameter
Item | Parameter |
---|---|
Model | DC4 |
Max. Doors | 4 |
User Capacity | 20,000 |
Record Capacity | 70,000 |
Access Group | 200 group |
Holiday Schedule | 64 group, 30 day/group |
Custom Wiegand | Yes (Max 66 bits) |
Door Open Time | 1 sec - 255 secs |
Working Voltage | DC 12V |
Working Current | Non-loaded <200mA |
TCP / IP | Yes |
RS485 | Yes |
Reader Port | 4 |
Working Temperature | -20℃-55℃ |
Working Humidity | 10%-90% |
Size | L178×W141×H20mm |
