Product Description
Product Parameter
| Item | Parameter |
|---|---|
| Model | DC4-PW1-BX1 |
| Max. Doors | 4 |
| User Capacity | 20,000 |
| Record Capacity | 70,000 |
| Access Group | 200 group |
| Holiday Schedule | 64 group, 30 day/group |
| Custom Wiegand | Yes (Max 66 bits) |
| Door Open Time | 1 sec - 255 secs |
| Working Voltage | DC 12V |
| Working Current | Non-loaded <200mA |
| TCP / IP | Yes |
| RS485 | Yes |
| Reader Port | 4 |
| Working Temperature | -20℃-55℃ |
| Working Humidity | 10%-90% |
| Size | L343×W243×H82mm |
